WLL-5C | 5T
Underground explosion-proof electric material carrier series adopts an integral frame design (hinged type is optional, equipped with allwheel steering system, timely four-wheel drive system, battery quick change system, new explosion-proof lithium battery with high energy density and driverless system. The whole vehicle has small turning radius, strong traffcability, strong power and good controlability, so as to eliminate mileage anxiety, With a high degree of inteligence and informatization, it is a new generation of mining intelligent vehicle platform to help smart mines and safe mines.
As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
EMAC Group Participates in Automechanika Istanbul Exhibition in Istanbul
As one of the largest automotive events in the world, the Automechanika Istanbul Show attracts exhibitors and visitors from across the globe. Our Company is excited to showcase its latest products and services at the event, which will provide an excellent opportunity to network with industry professionals and connect with potential customers.
EMAC Customer Interview-Thailand Engineering Company
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust !EMAC Customer Interview-Indonesia Shipyard
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!Identification and Classification Report for Air Transport of Goods
Advantages of AHI WLL-5C Rigid Frame Dump Truck
-
Convenient And safe: Low foor design, the space is large, improve occupant boarding,convenience,and safety.
-
Environmental protection: Using power lithium battery for power supply, zero emissions,low noise, energy conservation and environmental protection.
-
Strong power:Using variable frequency speed regulation system and high effcient drive system, powerful.
-
Comfortable drive:The layout of the vehicle used in line with the ergonomics design,vision,comfortable drive.
-
Intelligent Monitoring:The intelligent monitoring system,real-time monitor the working state of the motor, the reducer, the battery, and other important components.
Technical Specifications
| Truck Model： |
WLL-5C |
| Drive Form: | 4×4 Four wheel drive |
| Transmission Form: | All-wheel steering |
| Vehicle Size: | 6650 * 2000 * 2200 |
| Minimum Ground Clearance: | 200 mm |
| Approach Angle: | 18 ° |
| Departure Angle: | 25 ° |
| Rated Load Capacity: | 5000 kg |
| Curb Mass: | 8200 kg |
| Rated Passenger Capacity: | 2 person |
| Maximum speed: |
40 km/h |
| Mechanical Braking Distance: |
≤6m |
| Rated power of the motor: |
45 * 2 |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T,L/C |
Comming soon…
| Main Parameters Information of AHI WLL-5C Rigid Frame Dump Truck | |||
| Driving Form | 4×4 Four wheel drive | Curb mass | 8200 kg |
| Transmission Form | All-wheel steering | Rated Passenger Capacity | 2 person |
| Vehicle Size | 6650 * 2000 * 2200 | Maximum Speed | 40 km/h |
| Minimum Ground Clearance | 200 mm | Mechanical Braking Distance | ≤6 m |
| Approach Angle | 18 ° | Rated Power of the Motor | 45 * 2 kW |
| Departure Angle | 25 ° | Maximum Torque of the Motor | 700 * 2 N.m |
| Rated Load Capacity | 5500 kg | Range | 140 km |
Can Quality be Guaranteed?
(1)Strict production process and testing: The production process adopts advanced manufacturing technology and strict quality management system to ensure that each engine is precisely assembled and tested. Komatsu will conduct various performance tests, such as power test, emission test, etc., to ensure the running stability and reliability of the engine.
(2) Quality management system: Our company has a complete quality management system to ensure that every link meets strict quality standards.
(3) Continuous improvement and feedback mechanism: We focus on continuous improvement, communicate with customers through feedback mechanism, continuously optimize product quality and performance, and ensure that the needs of the market and customers are met.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
What should I do if I don’t Understand the Product?
You can unconditionally explain your needs to us. We have a professional team that uses simple and clear language to explain the characteristics and advantages of the product and help you choose the right engine to match your machine. If you need further support or explanation, we are always available to help and explain the relevant content to help you solve the problem.
How to Place an Order?
You can confirm the product by connecting with our sales, or you can choose to contact us through wahtspp or your email, and we will guide you to complete the order process.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
