WLJ-3B

The electric scraper truck is used for the handling and docking of large equipment in the reversion operation of large-scale mine relocation. Vehicle used lead-acid battery as the power source, wheel motor as power output, 4x 4 al-wheel drive, it is mainly composed of articulated frame, electric wheel, cab, scraper structure,traction mechanism and articulated steering mechanism, slewing mechanism electrical system, hydraulic system, intelligent management system, etc.

As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.

We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

EMAC Group Participates in Automechanika Istanbul Exhibition in Istanbul

EMAC Group, provide a one-stop service with a complete power chain for Automotive, has announced its participation in the Automechanika Istanbul Exhibition in Istanbul, Turkey. The exhibition will take place from June 8th to June 11th, 2023.
As one of the largest automotive events in the world, the Automechanika Istanbul Show attracts exhibitors and visitors from across the globe. Our Company is excited to showcase its latest products and services at the event, which will provide an excellent opportunity to network with industry professionals and connect with potential customers.

Learn More

EMAC Customer Interview-Thailand Engineering Company

EMAC’s customer interview video of 2023, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer’s company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC.
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust !

Learn More

EMAC Customer Interview-Indonesia Shipyard

Learn More

Identification and Classification Report for Air Transport of Goods

Sinomac is dedicated to providing customers with safe, reliable cargo transportation services. Whether by sea or by air, ensuring safe delivery of our clients’ goods is at the heart of our operations. However, due to the complex nature of some cargo, especially industrial equipment like engines, many clients have concerns about whether such items might be classified as dangerous goods in air transport. To address these concerns, Sinomac provides a detailed analysis from multiple perspectives, including engine structure, relevant regulations, and the evaluations of authoritative inspection bodies, to give clients a clear and professional answer to this question.

Learn More

Advantages of AHI WLJ-3B Concrete Mixer Truck

Great Power: Four wheel-side motor drive technology with great power.
Low Energy consumption: Electric braking and mechanical braking are combined to reduce energy consumption.
Extended life:Electric drive system forced cooling technology, extended life.
Efficient And Reliable:Effcient intelligent health management technology, effcient and reliable.
Convenient Maintenance:System confguration modular technology, maintenance is convenient.

Technical Specifications

Truck Model：	WLJ-3B
External Dimensions:	6900 * 1950 * 2300 mm
Vehicle Weight:	8800 kg
Rated Volume:	3 m³
Full Load Weight:	16000 kg
Min. Ground Clearance:	230 mm
Empty Front Axle:	63.7 %
Empty Rear Axle:	36.3 %
Fully Loaded Front Axle:	43.9 %
Fully Loaded Rear Axle:	56.1 %
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T,L/C

coming soon

Concrete Mixer Truck Model	Vehicle Weight	External Dimensions	Min. Ground Clearance	Full Load Weight
WLJ-3B	8800 kg	6900 * 1950 * 2300 mm	230 mm	16000 kg
——END——

Dimension Information of AHI WLJ-3B Concrete Mixer Truck
External Dimensions	6900 * 1950 * 2300 mm	Wheelbase	3700 mm
Min.Ground Clearance	230 mm	Axle Track	1590 mm

Mass Information of AHI WLJ-3B Concrete Mixer Truck
Vehicle Weight	8800 kg	Empty Rear Axle	36.3 %
Rated Volume	3 m³	Fully Loaded Front Axle	43.9 %
Full Load Weight	16000 kg	Fully Loaded Rear Axle	56.1 %
Empty Front Axle	63.7 %

Main Configuration of AHI WLJ-3B Concrete Mixer Truck
Battery Pack Rated Capacity	128 kWh	Pump Motor Rated Power	5.5 kW
Battery Pack Voltage Level	640 V	Pump Motor Voltage Level	640 V
Battery Pack Type of Battery	LFP	Intelligent Monitoring System	Optional
Drive Motor Voltage Level	640 V	Automatic Fire Protection System	Optional
Drive Motor Rated Power	2 * 45	Tire	36-12.5-20-28PR

Performance Parameter of AHI WLJ-3B Concrete Mixer Truck
Max. speed (empty / full load)	40	Min. outer Diameter of the Turning Channel Circle	14.4
Conprehensive Range(empty / full load)	65/76	Max. climbing Gradient (full load)	14
8km/h Braking Distance	6	Max. slope Gradient (full load)	14
Min. turning Diameter	13.3

Can Quality be Guaranteed?

(1)Strict production process and testing: The production process adopts advanced manufacturing technology and strict quality management system to ensure that each engine is precisely assembled and tested. Komatsu will conduct various performance tests, such as power test, emission test, etc., to ensure the running stability and reliability of the engine.
(2) Quality management system: Our company has a complete quality management system to ensure that every link meets strict quality standards.
(3) Continuous improvement and feedback mechanism: We focus on continuous improvement, communicate with customers through feedback mechanism, continuously optimize product quality and performance, and ensure that the needs of the market and customers are met.

Is the Price Reasonable?

We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.

What should I do if I don’t Understand the Product?

You can unconditionally explain your needs to us. We have a professional team that uses simple and clear language to explain the characteristics and advantages of the product and help you choose the right engine to match your machine. If you need further support or explanation, we are always available to help and explain the relevant content to help you solve the problem.

How to Place an Order?

You can confirm the product by connecting with our sales, or you can choose to contact us through wahtspp or your email, and we will guide you to complete the order process.
