Shovel Transporter Series
The Mining Explosion-proof Electric Scraper-Type Transporter is an electric transport equipment specifically designed for mining operations, featuring high efficiency, safety, and reliability. This transporter is designed with explosion-proof features, allowing it to safely operate in hazardous environments with explosive risks, ensuring the safety of both personnel and equipment. Its primary function is to transport materials in underground mines, such as coal and metal mines, and it is especially suitable for use in wet, flammable, and explosive mine environments.
The electric scraper-type transporter is equipped with an advanced electric drive system, providing strong traction and a large load capacity, enabling efficient transportation of ores and other materials in narrow and complex mining environments. Powered by electricity, the transporter not only saves energy compared to traditional internal combustion engines but also reduces environmental pollution.
In terms of safety, the Mining Explosion-proof Electric Scraper-Type Transporter complies with stringent international explosion-proof standards, ensuring stable operation in environments with potential explosive gases or dust. The equipment’s explosion-proof electrical control system is specially designed to effectively prevent sparks, overheating, and other factors that may trigger an explosion, ensuring safety in hazardous environments.
As part of EMAC, ConeMac integrates DCEC engines, provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.
The company provides customers with full life cycle services, from design to power system supply, installation and commissioning, to after-sales service training and spare parts supply, as well as troubleshooting and overhaul technical support. This full range of services ensures that customer equipment maintains high reliability and long-term operating efficiency during use.
These comprehensive power systems and service capabilities enable Duramac to occupy an important position in the field of construction machinery and provide advanced solutions for future electrification trends.
Shovel Transporter Series Main Feature
- Explosion-proof Design：Complies with international explosion-proof standards, ensuring safe operation in hazardous environments.
- Electric Drive System：Provides strong traction and reduces energy consumption, lowering environmental impact.
- Efficient Transport Capacity：Capable of transporting materials efficiently in narrow and complex mining environments.
- Durability：Built with high-quality materials for a long service life and reduced maintenance.
General Specifications of Shovel Transporter Series
| Vehicle Weight: | 55 – 150 t |
| Minimum Ground Clearance: | 210 – 270 mm |
| Payload Class: | 45 – 130 t |
| Full Load Weight: |
55 – 280 t |
Product Model |
Vehicle Weight |
Payload Class |
Product Model |
Vehicle Weight |
Payload Class |
||
| WCJ12Y |
22 t
|
12 t | WCJ60Y |
55 t
|
60 t | ||
| WJX-3FB |
17.5 t
|
3 t
|
WXP15 |
33 t
|
15 t
|
||
| WXP25 |
37 t
|
25 t | WXP45 |
58 t
|
45 t | ||
| WXP100 |
130 t
|
100 t
|
WXP130 |
143 t
|
130 t
|
||
| WXB45 |
55 t
|
45 t | WXB130 |
150 t
|
130 t | ||
| ——END—— | |||||||
Shovel Transporter Series
WXB130
Truck Model: WXB130
Oversize Dimension: 15650 * 4000 * 2500 mm
Minimum Ground Clearance: 270 mm
Vehicle Weight: 150 t
Full Load Weight: 280 t
WXB45
Truck Model: WXB45
Oversize Dimension: 12500 * 2850 * 1800 mm
Minimum Ground Clearance: 210 mm
Vehicle Weight: 55 t
Full Load Weight: 45 t
WXP25
Truck Model: WXP25
Oversize Dimension: 12300 * 2300 * 1800 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 37 t
Payload Class: 25 t
WXP130
Truck Model: WXP130
Oversize Dimension: 15600 * 4000 * 2500 mm
Minimum Ground Clearance: 275 mm
Vehicle Weight: 143 t
Payload Class: 130 t
WXP100
Truck Model: WXP100
Oversize Dimension: 14610 * 3910 * 2500 mm
Minimum Ground Clearance: 210 mm
Vehicle Weight: 130 t
Payload Class: 100 t
WXP45
Truck Model: WXP45
Oversize Dimension: 12465 * 2850 * 1800 mm
Minimum Ground Clearance: 210 mm
Vehicle Weight: 58 t
Payload Class: 45 t
WXP15
Truck Model: WXP15
Oversize Dimension: 11560 * 2760 * 1595 mm
Minimum Ground Clearance: 260 mm
Vehicle Weight: 33 t
Payload Class: 15 t
WJX-3FB
Truck Model: WJX-3FB
Oversize Dimension: 7818 * 1900 * 1600 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 17.5 t
Payload Class: 3 t
WCJ60Y
Truck Model: WCJ60Y
Oversize Dimension: 10050 * 3100 * 2020 mm
Minimum Ground Clearance: 200 mm
Vehicle Weight: 55 t
Payload Class: 60 t
WCJ12Y
Truck Model: WCJ12Y
Oversize Dimension: 10450 * 1850 * 2150 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 22 t
Payload Class: 12 t
