Open-pit Haul Dump Truck

This product is a high-performance mining truck that integrates safety, economy, intelligence, and comfort. Multiple active and passive safety systems and professional certification provide comprehensive protection. Its modular design and intelligent diagnostics facilitate maintenance and reduce operating costs. Its excellent load-to-weight ratio and low-emission engine significantly enhance economic efficiency. Reserved intelligent interfaces support autonomous driving upgrades, while the optimized chassis and cab design ensure exceptional driving comfort and controllability.

As part of EMAC, ConeMac integrates DCEC engines, provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.

The company provides customers with full life cycle services, from design to power system supply, installation and commissioning, to after-sales service training and spare parts supply, as well as troubleshooting and overhaul technical support. This full range of services ensures that customer equipment maintains high reliability and long-term operating efficiency during use.

These comprehensive power systems and service capabilities enable Duramac to occupy an important position in the field of construction machinery and provide advanced solutions for future electrification trends.

Advantages of Open-pit Haul Dump Truck

  • High Load Capacity: Spacious and durable cargo box enables efficient transport, featuring high-strength protective panels and linings for exceptional wear resistance.
  • Efficient Braking System: Equipped with a full hydraulic and electrical power brake system, it supports multiple braking modes under different conditions.
  • Flexible Steering: The full hydro-mechanical steering uses drag links to coordinate the steering trapezium with axle angles, achieving a minimum turning diameter of 24. m.

General Specifications of Open-pit Haul Dump Truck Series

Engine Power: 400 – 600 HP
Payload Capacity: 30 – 100 tons
Cargo Box Volume: 20 – 50 cubic meters
Maximum Speed: 50 – 70 km/h
Max Gradeability: 30 – 40 %
HT3110E 110 T
HT3130 120 T
HT3143 130 T
HT5220 220 T
HT3240 220 T
HT5240 220 T
HT3363 363 T
HT3150-LNG 136 T

Truck Model

Vehicle Weight/T

0 55 110 165 220 275 330 385

Open-pit Haul Dump Truck

This is the list of all series of Open-pit Haul Dump Truck.

HT3110E | 110T

HT3110E | 110T

Truck Model:HT3110E
Wheelbase: 5300 mm
Vehicle Weight: 90000 kg
Payload: 110000 kg
Min. Ground Clearance: ≥600 mm

HT3130 | 120T

HT3130 | 120T

Truck Model: HT3130
Payload Class: 120/118 ton
Empty Vehicle Weight: 90/88.6 ton
Gross Vehicle Weight: 205/201.8 ton
Max.Speed: 50 km/h

HT3143 | 130T

HT3143 | 130T

Truck Model: HT3143
Wheelbase: 5000 mm
Vehicle Weight: 110000 kg
Payload: 130000 kg
Min. Ground Clearance: 600 mm

HT5220 | 220T

HT5220 | 220T

Truck Model: HT5220
Payload Class: 220/240 ton
Empty Vehicle Weight: 168/185 ton
Gross Vehicle Weight: 388/426 ton
Max.Speed: 45 km/h

HT3143 | 130T

HT3240 | 220T

Truck Model:HT3240
Fuel Tank:4500 L
Rated Power:1600 kW
Max.torque: 9500 Nm
Rated Speed:1800 rpm

HT5240 | 220T

HT5240 | 220T

Truck Model: HT5240
Wheelbase:2970+3170+2970 mm
Vehicle Weight:165000 kg
Payload:220000 kg
Min. Ground Clearance:750 mm

HT3143 | 130T

HT3363 | 363T

Truck Model: HT3363
Payload Class: 363/400 ton
Empty Vehicle Weight: 237/261 ton
Gross Vehicle Weight: 600/661 ton
Max.Speed: 64 km/h

HT3143 | 130T

HT3150-LNG | 136T

Truck Model: HT3150-LNG
Vehicle Weight: 120000 kg
Payload: 136000 kg
Min. Ground Clearance: 600 mm
Rated Speed: 1800 rpm
