HT5240 | 220T
AHI HT5240 is an electric-drive mining dump truck with a rated load capacity of 200 tons, designed to meet the rigorous demands of large-scale open-pit mining operations. With a high localization rate of 95%, this truck combines advanced technology with cost-effective operation. The AHI HT5240 is equipped with a powerful electric-drive system and a reinforced welded rigid frame, ensuring exceptional durability and performance in challenging environments. Its MacPherson oil-gas spring front suspension provides superior shock absorption and stability, while the full-hydraulic steering system offers precise control and smooth handling during operation. The use of domestically produced components significantly reduces both maintenance costs and operational downtime. Built for long-lasting reliability and efficiency, the AHI HT5240 is the ideal choice for heavy-duty transportation tasks in the mining sector, ensuring a low total cost of ownership and optimized productivity.
As part of EMAC, ConeMac provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
EMAC Group Participates in Automechanika Istanbul Exhibition in Istanbul
As one of the largest automotive events in the world, the Automechanika Istanbul Show attracts exhibitors and visitors from across the globe. Our Company is excited to showcase its latest products and services at the event, which will provide an excellent opportunity to network with industry professionals and connect with potential customers.
EMAC Customer Interview-Thailand Engineering Company
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust !EMAC Customer Interview-Indonesia Shipyard
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!Identification and Classification Report for Air Transport of Goods
Advantages of AHI HT5240 Hual Truck
-
Energy saving: Can be equipped with LNG hybrid engine, achieve environmental protection and energy saving.
-
Economic stability: Higher payload capacity,excellent fuel effciency,Wide distance between supporting point of the dump body, the truck is reliable.
-
Long service Life: AC electric drive system, low maintenance cost and long lifetime,Independent dual rear axles + swing axle + four rear independent driving tires design, the truck is more powerful, each tire’s load is
evenly and lifetime is longer. -
Intelligent extension: The truck setting meets the requirements ofintelligent interface,which can realize unmanned driving rapid transformation of vehicles, and effectively promote theinnovative development of smart mines.
Technical Specifications
| Truck Model： |
HT5240 |
| Drive Model: | 4* 2 |
| External Dimensions(L*W*H): | 15000*7200*6980 mm |
| Wheelbase: | 2970+3170+2970 mm |
| Vehicle Weight: | 165000 kg |
| Payload: |
220000 kg |
| Min. Ground Clearance: | 750 mm |
| Fuel Tank： | 3100 L |
| Rated Power： | 2*895 kW |
| Max.torque： | 2*4670 Nm |
| Rated Speed： | 1900 rpm |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T,L/C |
Hual Truck Model |
Payload Class |
Vehicle Weight |
External Dimensions |
Min. Ground Clearance |
| HT3110E |
110 t
|
90 t | 11610 * 6600 * 6420 mm | ≥600 mm |
| HT3130 |
120 t
|
110 t | 12120 * 7530 * 6100 mm | 600 mm |
| HT3143 |
130 t
|
110 t | 11840 * 7530 * 6070 mm | 600 mm |
| HT5220 |
220 t
|
110 t | 15790 * 9500 * 7810 mm | 800 mm |
| HT3240 |
220 t
|
165 t | 14500 * 7500 * 6910 mm | 800 mm |
| HT5240 |
220 t
|
165 t | 15000 * 7200 * 6980 mm | 800 mm |
| HT3363 |
363 t
|
237 t | 15790 * 9500 * 7810 mm | 800 mm |
| HT3150-LNG |
136 t
|
120 t | 12120 * 7530 * 6100 mm | 600 mm |
| ——END—— | ||||
| Dimension Information of AHI HT5240 Hual Truck | |||
| External Dimensions(L * W * H) | 15000x7200x6980 mm | Min. ground Clearance | 750 mm |
| Wheelbase | 2970+3170+2970 mm | Max. angle of Bucket Lifting | 50° |
| Front and Rear Wheelbase | 4550 mm | ||
| Mass Parameters of AHI HT5240 Hual Truck | |||
| Vehicle Weight | 165000 kg | Hydraulic Oil Tank Capacity | 1300 L |
| Payload | 220000 kg | Empty Front Axle | 61 % |
| Container Capacity(Standard Flat Loading) | 110 m³ | Empty Rear Axle | 39 % |
| Container Capacity(Stacking) | 140 m³ | Fully Loaded Front Axle | 49 % |
| Fuel tank | 3100 L | Fully Loaded Rear Axle | 51 % |
| Main Configuration of AHI HT5240 Haul Dump Truck | |||
| Engine Rated Power | 2*895 kW | Traction Motor Rated Power | 12 * 110 kW |
| Engine Max.torque | 2*4670 Nm | Traction Motor Max. speed | 3300 rpm |
| Engine Rated Speed | 1900 rpm | Gearbox Reduction Ratio | 29.27 |
| Engine Weight | 2*3700 kg | Gearbox Driving Brake Mode | Full dry braking |
| Power Battery Capacity | N/A | Traction Inverter+braking Resistor Box | Equip |
| Main Generator Voltage Level | 1200 VAC | Centralized Lubrication System | Equip |
| Main Generator Rated Power | 2*900 kW | Automatic Fire Protection System | Equip |
| Performance Parameter of AHI HT5240 Haul Dump Truck | |||
| Min. turning Diameter | 25 m | Rated Climbing Gradient (full load) | 8%,≥12 km/h |
| Max. speed Without Load | 45 km/h | Max. climbing Gradient (full load) | 22 % |
| Max. speed Under Full Load | 30 km/h | Max. slope Gradient (full load) | 20 % |
| 30km/h Acceleration Time (full load) | 25 s | Container Lifting/Falling Time | 26/22 s |
| 30km/h Braking Distance | 25 m | Driverless System | Optional |
Can Quality be Guaranteed?
(1)Strict production process and testing: The production process adopts advanced manufacturing technology and strict quality management system to ensure that each engine is precisely assembled and tested. Komatsu will conduct various performance tests, such as power test, emission test, etc., to ensure the running stability and reliability of the engine.
(2) Quality management system: Our company has a complete quality management system to ensure that every link meets strict quality standards.
(3) Continuous improvement and feedback mechanism: We focus on continuous improvement, communicate with customers through feedback mechanism, continuously optimize product quality and performance, and ensure that the needs of the market and customers are met.
Is the Price Reasonable?
We are the original manufacturer and can give you the most suitable price. The key to dealing with Chinese suppliers is to find and choose reliable business partners who will not deceive you for short-term business, but aim to establish a long-term career and lifelong partnership. EMAC is one of the reliable partners. We will not pursue short-term high profits, but we care about our decades of good reputation. Our cooperation with all business partners is not only as suppliers and customers, but also as close friends and brothers.
What should I do if I don’t Understand the Product?
You can unconditionally explain your needs to us. We have a professional team that uses simple and clear language to explain the characteristics and advantages of the product and help you choose the right engine to match your machine. If you need further support or explanation, we are always available to help and explain the relevant content to help you solve the problem.
How to Place an Order?
You can confirm the product by connecting with our sales, or you can choose to contact us through wahtspp or your email, and we will guide you to complete the order process.
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
