Handling Transporter Series
integral frame-type hydraulic support handling transporter is a new type of special vehicle, used for hydraulic support handling or transport over long distances, is an essential part of modern underground mining technology of auxiliary transportation equipment changed the traditional hydraulic support handling carrier type,”U” type framework adopts whole frame and the compensation function of suspension system with the road, with heavy loading ability, compact structure, small turning radius and high reliability, etc.it can carry the extra long bracket, which has a wide range of adaptability.
The hydraulic support handling vehicle is specifically for the transportation and long-distance transportation of hydraulic supports during the moving of coal mine underground fully mechanized mining faces, it subverts traditional design ideas and builds a new technology platform for the overall framework hydraulic support handling vehicle by adopting a frame design, multi axis, all wheel drive, all wheel steering and other technologies, it solves the shortcomings of traditional bracket handling vehicles and provides a new technological path for the development of bracket handling vehicles, making it an essential auxiliary transportation equipment for modern coal mining processes.As part of EMAC, ConeMac integrates DCEC engines, provides industrial power pack solution that integrated with air intake, air exhaust, cooling system, control system, transmission and hydraulic accessories, We also supplying special products such as explosion proof engine, generator and water pump set, as well as ultra-low temperature condition engine power pack.
The company provides customers with full life cycle services, from design to power system supply, installation and commissioning, to after-sales service training and spare parts supply, as well as troubleshooting and overhaul technical support. This full range of services ensures that customer equipment maintains high reliability and long-term operating efficiency during use.
These comprehensive power systems and service capabilities enable Duramac to occupy an important position in the field of construction machinery and provide advanced solutions for future electrification trends.
Handling Transporter Series Main Feature
- Flexible control: Overall frame design, fexible control.
- High oriving efficiency: Driven by static hydraulic closed drive system, high effciency.
- Reliable draking:Multi-mode hydraulic brake, safe and reliable braking.
- Good oriving experience:Suspension system have road compensation function, good damping effect and driving comfort.
- Hydraulic Transmission:Main function adopts hydraulic transmission technology, excellent explosion-proof performance.
- Good Maintainability:The vehicle adopts modular design idea, good maintainability.
General Specifications of Handling Transporter Series
| Vehicle Weight: | 32 – 55 t |
| Payload Class: | 25 – 130 t |
| No Load Speed: | 8 – 16 km/h |
| Full Load Speed: |
5 – 16 km/h |
Handling Transporter Series
This is the list of all series of Handling Transporter Series.
WC130Y
Truck Model: WC130Y
Oversize Dimension: 10500 * 4500 * 2600 mm
Minimum Ground Clearance: 280 mm
Vehicle Weight: 48 t
Payload Class: 130 t
WC100Y
Truck Model: WC100Y
Oversize Dimension: 8800 * 4500 * 2600 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 55 t
Payload Class: 100 t
WC80Y
Truck Model: WC80Y
Oversize Dimension: 8600 * 4000 * 2300 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 40 t
Payload Class: 80 t
WC60Y
Truck Model: WC60Y
Oversize Dimension: 7500 * 3700 * 2400 mm
Minimum Ground Clearance: 250 mm
Vehicle Weight: 32 t
Payload Class: 60 t
WX25J
Truck Model: WX25J
Oversize Dimension: 11200 * 2200 * 1800 mm
Minimum Ground Clearance: 300 mm
Vehicle Weight: 33 t
Payload Class: 25 t
